Introducing openstatsware and the R Package {mmrm}

R/Pharma 2023 Conference

Ya Wang on behalf of the working group


Introducing the Working Group


  • Official working group of the American Statistical Association (ASA) Biopharmaceutical Section
    • Formed on 19 August 2022
    • Cross-industry collaboration (55 members from 36 organizations)
    • Full name: Software Engineering Working Group
    • Short name: openstatsware
    • Homepage:

Working Group Objectives

  • Primary
    • Engineer R packages that implement important statistical methods
      • to fill in gaps in the open-source statistical software landscape
      • focusing on what is needed for biopharmaceutical applications
  • Secondary
    • Develop and disseminate best practices for engineering high-quality open-source statistical software
      • By actively doing the statistical engineering work together, we align on best practices and can communicate these to others

Workstreams in R Package Development

  • Mixed Models for Repeated Measures (MMRM) 🌎
    • Develop mmrm R package for frequentist inference in MMRM (CRAN)
  • Bayesian MMRM 🌎
    • Develop brms.mmrm R package for Bayesian inference in MMRM (CRAN)
  • Health Technology Assessment 🌎
    • Develop open-source R tools to support HTA dossier submission across various countries
    • Particularly topics with unmet needs in R implementation and/or related to EUnetHTA

Best Practices Dissemination

  • Workshop “Good Software Engineering Practice for R Packages” on world tour
    • to teach hands-on skills and tools to engineer reliable R packages
    • 5 events so far at Basel, Shanghai, San José, Rockville, and Montreal
  • Youtube video series “Statistical Software Engineering 101” 🌎
    • to introduce tips and tricks for good statistical software engineering practices
    • 2 videos so far

R Package mmrm


  • MMRM is a popular choice for analyzing longitudinal continuous outcomes in randomized clinical trials
  • No great R package
    • Initially thought that the MMRM problem was solved by using lme4 with lmerTest, learned that this approach failed on large data sets (slow, did not converge)
    • nlme does not give Satterthwaite adjusted degrees of freedom, has convergence issues, and with emmeans it is only approximate
    • Next we tried to extend glmmTMB to calculate Satterthwaite adjusted degrees of freedom, but it did not work


  • We only want to fit a fixed effects model with a structured covariance matrix for each subject
  • The idea is then to use the Template Model Builder (TMB) directly - as it is also underlying glmmTMB - but code the exact model we want
  • We do this by implementing the log-likelihood in C++ using the TMB provided libraries

Advantages of TMB

  • Fast C++ framework for defining objective functions (Rcpp would have been alternative interface)
  • Automatic differentiation of the log-likelihood as a function of the variance parameters
  • We get the gradient and Hessian exactly and without additional coding
  • This can be used from the R side with the TMB interface and plugged into optimizers

Why It’s Not Just Another Package

  • Ongoing maintenance and support from the pharmaceutical industry
    • 5 companies being involved in the development, on track to become standard package
  • Development using best practices as show case for high quality package
    • Thorough unit and integration tests (also comparing with SAS results) to ensure accurate results

Features of mmrm

  • Linear model for dependent observations within independent subjects
  • Covariance structures for the dependent observations:
    • Unstructured, Toeplitz, AR1, compound symmetry, ante-dependence, spatial exponential
    • Allows group specific covariance estimates and weights
  • REML or ML estimation, using multiple optimizers if needed
  • emmeans interface for least square means
  • tidymodels for easy model fitting
  • Satterthwaite and Kenward-Roger adjustments
  • Robust sandwich estimator for covariance

Comparison with Other Software

  • We have run comparison analyses with other R packages, namely nlme, glmmTMB and lme4
  • Also compared with SAS PROC GLIMMIX
  • Highlights
    • mmrm has faster convergence time
    • mmrm provides closest results to PROC GLIMMIX
  • Detailed results at the online comparison vignette
